Concrete Component Forming Machine HY3200

This molding machine can be applied to the production of a variety of concrete precast components, such as the farm leakage plate,municipal trench, cover plate and other concrete precast components. Adopting the processes of workstation mobility, instant molding, and instant demolding effectively enhances production efficiency, reduces site space and labor requirements, and ensures better product quality.

+86 595-22682555

Features

1. The efficient drive system utilizes a frequency conversion system from internationally renowned brands.
2. The precise and energy-efficient hydraulic system, which uses servo drives, ensures accurate movements and reduces energy consumption, making it less prone to oil temperature increases.
3. A powerful vibration system, four powerful vibrators are installed on the same vibration beam, vibration transmission is efficient, vibration frequency and amplitude are flexibly adjusted to adapt to material changes.
4. Advanced control system, using first-class international brands, combined with the targeted development of the control system makes the operation easy and easyt.
5. The exquisite cloth system cleverly combines material distribution, cloth, scraping and smoothing, making it more flexible and efficient.

Parameter

Max Product Size	3400×1250mm	Hopper Height	1600mm
Rotray Height	1.1m	Hopper Strorage	1.5m³
Max Demoulding Height	200mm	Machine Size	8660×4000×4340mm
Power	62Kw	Machine Weight	30T
Vibrator Qty	4	Max Product Weight	1T
Vibration	260KN	Max Mould Weight	3T
Voitage	380V	Cycle Time	5-12min
